| Specification | |
| LCD type | transflective 3.5" tft lcd |
| Display type | 3.5" TFT, normal white |
| Touch panel | without |
| Description | transflective 3.5" tft lcd |
| Driver element | a-si TFT Active matrix |
| Outline Dimension(mm) | 85.0x53.64x2.93 |
| v.A(mm) | 74.52x56.54 |
| A.A.(mm) | 71.52x53.64 |
| Driver IC | ILI9341 |
| Resolution(dots)_ | 320*RGB*240 |
| Viewing Direction | 6H |
| Operating temperature(°C) | -20-70 |
| Storage temperature(°C) | -30-80 |
| Number of Pixel(pixels) | 240 (H) x 3 RGB x 2400 (V) |
| Pixelanordnung | Vertikaler RGB-Streifen |
| Anzeigemodus | Normalerweise weiß |
| Oberflächenbehandlung | Blendschutz, Hartbeschichtung (3H) |
| Gewicht (g) | offen |
| Hintergrundbeleuchtung | 6 LEDs, weiß |
| Gewicht (g) | offen |
| Modullebensdauer (Stunden) | 50.000-100.000 |
