Neue und stabile 3.97 Zoll 480x800 Auflösung, IPS-Farbdisplay mit MIPI-Schnittstelle

Neue und stabile 3.97 Zoll 480x800 Auflösung, IPS-Farbdisplay mit MIPI-Schnittstelle



  • Item no.:

    TST040WVHS-16
  • Zahlung:

    EXW
  • Produkt Herkunft:

    China
  • Min um:

    1000
  • Versand port:

    Shenzhen
  • Vorlaufzeit:

    4~5 weeks

Neue und stabile 3.97 Zoll 480x800 Auflösung, IPS-Farbdisplay mit MIPI-Schnittstelle

Spezifikation
Artikel NR. TST040WVHS-16
Outline Dimension(mm)
57.143 mm x96.853mm x2.0mm
Aktive Fläche(mm) 51.84mmx86.4mm
Auflösung(Punkte) 480*RGB*800
Betriebstemperatur(°C) -20-70
Lagertemperatur(°C) -30-80
Anzahl der Pixel(Pixel) 480RGB(H)xRGBx800(V)
Touch-panel ohne
Treiber-IC ILI9806E
Pixel-Anordnung Vertikaler Streifen RGB
Display-Modus Normal, schwarz,IPS, 3.97 Zoll-TFT -
Oberflächenbehandlung Entspiegelte
Blick Richtung ALLE
Gewicht(g) TBD
Leistungsaufnahme(w) Panel 0.226(Typ.)
B/L-system 1.674(Typ.)
Schnittstelle RGB
Modul-Lebensdauer(Stunden) 50,000-100,000
Holen Sie Sich Ein Angebot
Wenn Sie an unseren Produkten interessiert sind und mehr details wissen wollen,bitte hier eine Nachricht hinterlassen,wir Antworten Ihnen so schnell wie wir können.
